Comparative Evaluation of Multidetector Computed Tomography Angiography & Color Doppler Ultrasonography in Lower Limb Peripheral Arterial Disease

Abstract

Introduction: Peripheral arterial disease (PAD) is a common vascular disorder that necessitates precise imaging for accurate diagnosis and effective management. Among the available non-invasive imaging techniques, Color Doppler Ultrasonography (CDUS) and Multidetector Computed Tomography Angiography (MDCTA) are widely utilized, each offering unique benefits in vascular assessment.

Aims & Objectives: This study aimed to evaluate and compare the diagnostic performance of CDUS and MDCTA in patients with lower limb PAD, focusing on their sensitivity, specificity, overall accuracy in grading arterial stenosis.

Materials & Methods: A hospital-based descriptive cross-sectional study was carried out on 48 patients, accounting for 96 lower limbs, all clinically suspected of having PAD. Each participant underwent both CDUS and MDCTA examinations. Arterial stenosis was categorized into five groups: normal, mild (≤50%), moderate (50–70%), severe (≥70%), and complete occlusion. Statistical analysis was conducted using IBM SPSS version 26, with a p-value of less than 0.05 considered statistically significant.

Results: Most participants were male (72.9%), with the highest proportion falling within the 61–70 years age group (39.6%). Claudication emerged as the most frequent presenting complaint (44.8%). CDUS demonstrated excellent sensitivity (100%) and high specificity (89.7%) when compared with MDCTA, achieving an overall diagnostic accuracy of 93.6%. There was near-perfect agreement between the two modalities (κ = 0.86), along with strong diagnostic performance (AUC = 0.93). However, CDUS showed a tendency to overestimate stenosis in infrapopliteal segments, where specificity was relatively reduced, while MDCTA provided better visualization of distal vessels.

Conclusion: CDUS serves as a highly sensitive, non-invasive screening tool, especially effective for proximal arterial segments. MDCTA remains a reliable reference standard, offering superior anatomical detail and precise stenosis grading necessary for treatment planning. A combined imaging approach enhances diagnostic accuracy, particularly for evaluating distal arterial involvement.

REFERENCES:

1. Haider R. Peripheral vascular disease. Cardiol Res Rep. 2023;5(4):1-13.
2. AbuRahma AF, Campbell JE. Overview of peripheral arterial disease of the lower extremity. In: AbuRahma AF, Bergan JJ, editors. Noninvasive Vascular Diagnosis: A Practical Textbook for Clinicians. Cham: Springer; 2022:449-488. https://doi.org/10.1007/978-3-030-60626-8_21
3. Khanna NN, Krishna V, Manjunath CN, Tyagi S, Jindal R, Chadha M, et al. The Indian consensus statement for the management of lower extremity peripheral artery disease. J Indian Coll Cardiol. 2023;13(1):1-20. https://doi.org/10.4103/1561-8811.383634
4. Krishnan MN, Geevar Z, Mohanan PP, Venugopal K, Devika S. Prevalence of peripheral artery disease and risk factors in the elderly: a community-based cross-sectional study from northern Kerala, India. Indian Heart J. 2018;70(6):808-815. https://doi.org/10.1016/j.ihj.2017.11.001
5. Fowkes FG, Aboyans V, Fowkes FJ, McDermott MM, Sampson UK, Criqui MH. Peripheral artery disease: epidemiology and global perspectives. Nat Rev Cardiol. 2017;14(3):156-170. https://doi.org/10.1038/nrcardio.2016.179
6. Abu-Fadel M. Complications of peripheral arterial interventions. In: Practical Approach to Peripheral Arterial Chronic Total Occlusions. Singapore: Springer; 2017: 95-122. https://doi.org/10.1007/978-981-10-3053-6_7
7. Narula N, Dannenberg AJ, Olin JW, Bhatt DL, Johnson KW, Nadkarni G, et al. Pathology of peripheral artery disease in patients with critical limb ischemia. J Am Coll Cardiol. 2018;72(18):2152-2163. https://doi.org/10.1016/j.jacc.2018.08.002
8. Bernatchez J, Fortin W, Boisvert A, Douville Y, Mao Y, Philippe É, et al. Peripheral arterial disease: what you need to know. In: Cardiovascular Explants: Biofunctionality, Biodurability and Biocompatibility. Cham: Springer Nature Switzerland; 2025: 91-139. https://doi.org/10.1007/978-3-031-85504-7_3
9. Sgroi MD, Chou EL, Wilson SE. Clinical examination of the vascular system. In: Vascular Surgery. Boca Raton (FL): CRC Press; 2017:79-88.
10. Pollak AW, Norton PT, Kramer CM. Multimodality imaging of lower extremity peripheral arterial disease: current role and future directions. Circ Cardiovasc Imaging. 2012;5(6):797-807. https://doi.org/10.1161/circimaging.111.970814
11. Collins R, Burch J, Cranny G, Aguiar-Ibáñez R, Craig D, Wright K, et al. Duplex ultrasonography, magnetic resonance angiography, and computed tomography angiography for diagnosis and assessment of symptomatic lower limb peripheral arterial disease: systematic review. BMJ. 2007;334(7606):1-9. https://doi.org/10.1136/bmj.39217.473275.55
12. Tanaka R, Yoshioka K. Subtraction CT angiography for the evaluation of lower extremity artery disease with severe arterial calcification. J Cardiovasc Dev Dis. 2025;12(4):1-12. https://doi.org/10.3390/jcdd12040131
13. Malaichamy A, Pandian V, Arumugam T, Ravipati C, Malaichamy Sr A. Advances in vascular imaging: a comparative analysis of Doppler ultrasound and multidetector CT for lower limb peripheral arterial disease diagnosis. Cureus. 2024;16(6):1-10. https://doi.org/10.7759/cureus.62673
14. Zakir M, Tazeen A, Khan FN, Fatima M, Tauqir J, Ahmad T. Comparison of color Doppler and computed tomography angiography in arterial disease in patients with lower limb ischemia. Prof Med J. 2021;28(10):1381-1391. https://doi.org/10.29309/tpmj/2021.28.10.6375
15. Cansu A, Soyturk M, Ozturk MH, Kul S, Pulathan Z, Dinc H. Diagnostic value of color Doppler ultrasonography and MDCT angiography in complications of hemodialysis fistulas and grafts. Eur J Radiol. 2013;82(9):1436-1443. https://doi.org/10.1016/j.ejrad.2013.03.015
16. Lin YH, Tsai PS, Hung CL, Beg MF, Yeh HI, Yun CH, et al. The role of muscle density in predicting the amputation risk in peripheral arterial disease: a tissue composition study using lower extremity CT angiography. Diagnostics (Basel). 2025;15(11):1-15. https://doi.org/10.3390/diagnostics15111439
17. Pan Z, Wang R, Li L, Zhang H. Correlation between significant asymptomatic carotid artery stenosis and severity of peripheral arterial occlusive disease in the lower limb: a retrospective study on 200 patients. BMC Neurol. 2019;19(1):1-5. https://doi.org/10.1186/s12883-019-1485-1
18. Raskin D, Khaitovich B, Silverberg D, Halak M, Balan S, Rimon U. Primary retrograde dorsalis pedis artery single access for revascularization of chronic total occlusion in patients with critical limb ischemia. J Vasc Interv Radiol. 2019;30(4):554-559. https://doi.org/10.1016/j.jvir.2018.08.030
19. Kayhan A, Palabıyık F, Serinsöz S, Kırış A, Bayramoğlu S, Williams JT, et al. Multidetector CT angiography versus arterial duplex USG in diagnosis of mild lower extremity peripheral arterial disease: is multidetector CT a valuable screening tool? Eur J Radiol. 2012;81(3):542-546. https://doi.org/10.1016/j.ejrad.2011.01.100
20. Kosmala A, Weng AM, Schmid A, Gruschwitz P, Grunz JP, Bley TA, et al. Dual-energy CT angiography in peripheral arterial occlusive disease: diagnostic accuracy of different image reconstruction approaches. Acad Radiol. 2022;29:59-68. https://doi.org/10.1016/j.acra.2020.10.028
21. Elsaied FM, Sherief HM, Abdelwahab M. Reliability and dependency of color-coded duplex ultrasonography in comparison to multidetector computed tomography angiography in diagnosis and selection of treatment strategy of peripheral arterial disease of the lower limb. Al-Azhar Assiut Med J. 2015;13(4):116-119. https://doi.org/10.1136/bmj.c1298
22. Zhiqiang L, Yihua W, Ying F, Shiwei Z, Xiangzhu Z, Ligang C. The value of color Doppler ultrasonography combined with computed tomography angiography and magnetic resonance angiography in the preoperative quantification and classification of carotid body tumors: a retrospective analysis. BMC Med Imaging. 2024;24(1):1-10. https://doi.org/10.1186/s12880-023-01189-x
23. Sultan W, Ahmad J, Kanwal P. Role of CT angiography and Doppler ultrasound in the evaluation of peripheral vascular diseases: a review on diagnostic challenges and insights from special populations. Electron J Med Res. 2025;1(1):78-95. https://doi.org/10.64813/ejmr.2025.014
